WEIHONG 200 Series Manufacturer's Manual

上海维宏电子科技股份有限公司
Weihong Electronic Technology Co., Ltd.
- 22 - Specialized, Concentrated, Focused
Group
Silk-printed
Name
Software
Definition
Description
Z-axis
brake
BRAKE
Brake control
Connected to the brake output signal of the
servo driver.
BK+, BK-
Two ends of brake
input
Controlling the 24V on/off of the motor brake
line.
Signal light
RED
Red alarm lamp
Red light on when machining ends or during
E-stop.
GREEN
Green work lamp
Light on during normal working state of machine.
YELLOW
Yellow work lamp
Yellow light on during idle state after machining
ends or during waiting state.
Commonly
used output
OIL
Lubrication on
Controlling lubrication pump on/off.
COOL
Workpiece
cooling
Controlling the workpiece cooling switch.
LAMP
Illumination
Controlling the on/off of the illuminating lamp.
GY13
Spindle CCW
Controlling the switch of spindle CCW rotating.
GY12
Tool blow
Controlling the switch to blow the tool.
GY11
Tool magazine
CW
Controlling the switch of tool magazine CW.
GY10
Tool magazine
CCW
Controlling the switch of tool magazine CCW.
Reserved
input
GX58
Reserved input
Available for custom reserved input.
2.2.2.2 Dual Z System
Group
Silk-printed
Name
Software
Definition
Description
External
power
+24V
DC 24V power
Terminal board should be powered by external
power supply.
COM
REF. point
signal
X0
X machine origin
Binary input, low level effective; connected to
home switch of X-axis.
Y0
Y machine origin
Binary input, low level effective; connected to
home switch of Y-axis.
Z10
Z1 machine origin
Binary input, low level effective; connected to
home switch of Z1-axis.
Z20
Z2 machine origin
Binary input, low level effective; connected to
home switch of Z2-axis.
COM
Common port
Signal common port.
Limit signal
XLAM+
X positive limit
Binary input, low level effective; connected to
positive limit switch of X-axis.
XLAM-
X negative limit
Binary input, low level effective; connected to
negative limit switch of X-axis.
YLAM+
Y positive limit
Binary input, low level effective; connected to
positive limit switch of Y-axis.
YLAM-
Y negative limit
Binary input, low level effective; connected to
negative limit switch of Y-axis.
