WEIHONG 200 Series Manufacturer's Manual

上海维宏电子科技股份有限公司
Weihong Electronic Technology Co., Ltd.
Specialized, Concentrated, Focused - 147 -
Name
Setting Range
Default
Value
When
Enabled
Refer-
ence
movement
2: Z Down Feedrate Limitation
valid with Z-axis downward
movement included
Z Down Speed
0.0 ~ MAX Axial Velocity (Z)
(mm/ min)
300
Immediately
3.9.3
Z Deceleration Distance
0~999 (mm)
10
Immediately
3.9.3
Z Approach Speed
0~ Default Feedrate (mm/min)
600
Immediately
3.9.3
MAX X axis speed
6~15000 (mm/min)
10000
After restart
3.9.3
MAX Y axis speed
6~15000 (mm/min)
10000
After restart
3.9.3
MAX Z axis speed
Z Down Feedrate Limitation ~
6000000 (mm/min)
10000
After restart
3.9.3
Reference Velocity in
Corner
0.1667~10000(mm/min)
500
After restart
3.9.3
X axis Reference Velocity
in Corner
0.1667~10000(mm/min)
500
After restart
3.9.3
Y axis Reference Velocity
in Corner
0.1667~10000(mm/min)
500
After restart
3.9.3
Z axis Reference Velocity
in Corner
0.1667~10000(mm/min)
500
After restart
3.9.3
A axis Reference Velocity
in Corner
0.1667~10000(mm/min)
500
After restart
3.9.3
Reference Circular Speed
Yes: Valid
No: Invalid
Yes
Immediately
3.9.3
Reference Circle Speed
5~99999 (mm/min)
3500
Immediately
3.9.3
Limit Max Velocity for
Small Line
Yes: Valid
No: Invalid
Yes
Immediately
-
Length for Limit Max
Velocity
0.001~100000 (mm)
2
Immediately
-
Path Smoothing Time
0~2 (sec)
0
Immediately
-
Arc Radius Tolerance
0~999 (mm)
2
Immediately
-
Enable Arc IJK
incremental mode
Yes: Valid
No: Invalid
Yes
Immediately
-
Spindle Off while Pausing
Yes: Valid
No: Invalid
Yes
After restart
3.4
Spindle Off while Stopping
Yes: Valid
No: Invalid
Yes
After restart
-
Is open coolant while
starting
Yes: Valid
No: Invalid
No
After restart
-
Is close coolant while
stopping
Yes: Valid
No: Invalid
No
After restart
3.4
Spindle Off when Cycle
Completed
Yes: Stop
No: Not stop
Yes
Immediately
3.4
MAX Spindle Speed
10000~999999 (r/min)
24000
After restart
3.4
Spindle start/stop time
0~60000 (ms)
5000
Immediately
3.4
Spindle Action Options
when Cycle Completed
0:Not move
1: Back to fixed point
2: Back to workpiece origin
0
Immediately
3.4
Prompt after machining
ends
0: Red light not on
1: Red light on for 3s
2: Red light not off until there is
0
Immediately
3.4
