上海维宏电子科技股份有限公司
Weihong Electronic Technology Co., Ltd.
Specialized, Concentrated, Focused - 133 -
6.2 Wiring Diagram of NK280 Host and Differential Input
Stepping Driver
X-axis Stepping Driver
P+
P-
D-
Signal
PLU+
DIR+
PLU-
DIR-
Y-axis Stepping Driver
Z-axis Stepping Driver
NK280 Host
D+
Note: twisted cable used for differential signals
Pin
11
12
13
14
P+
P-
D-
Signal
PLU+
DIR+
PLU-
DIR-
D+
Pin
11
12
13
14
P+
P-
D-
Signal
PLU+
DIR+
PLU-
DIR-
D+
Pin
11
12
13
14
X
Y
Z
Fig. 6-1 Wiring diagram of terminal board and differential input stepping driver
