Specialized, Concentrated, Focused - 43 -
Pressing down F2 or F3 will make indicator light before the port selected shift between green and
red. And green light means there is signal in the port; red light means there is no signal in the port.
This group of buttons is mainly used for analog hardware signal, which is for simulation test.
Note:
The indicator lights before ports are slight different in test mode and in real practice:
Green light in test mode: Red light in test mode:
Green light in practice: Red light in practice:
[Cancel Test]
The shortcut key is F4, which is only available on [Port (A)] screen.
Press F4 to cancel simulation test and signal to replace analog signal with real hardware signal.
[Board View]
The shortcut key is F7, which is only available on [Port (A)] screen.
Pressing F7 will display the terminal board screen.
