following 4 types: velocity, acceleration, reference circle & circular speed limit, and interpolation
algorithm.
 Related Parameters of Velocity
Parameter
Definition
Setting Range
Manual High Speed
There are two speed modes for option under
manual mode: jog feedrate and rapid jog
feedrate, which can be switched by pressing the
acceleration key. The system default running
speed mode is jog feedrate mode.
Manual Low Speed ~
MAX Axial Velocity
(mm/min)
Manual Low Speed
0.001~ Manual High
Speed (mm/min)
Dry running speed
(G00)
It refers to the feedrate specified by command
G00.
-
Machining Speed
(Gxx)
It refers to the feedrate specified by command
Gxx.
-
Startup Speed
The minimum speed in machining.
0~Z-axis Approach
Speed (mm/min)
Full feedrate for G00
When it is set as ―Yes‖, G00 override will be not
controlled by the override switch, but fixed at
100%.
Yes: Valid
No: Invalid
Feedrate is valid for
manual mode
When it is set as ―Yes‖, feedrate override is
adjusted in manual operation; ―No‖, feedrate
override is fixed at 100%.
Yes: Valid
No: Invalid
Use Default Speed
When it is set as ―Yes‖, the system will not adopt
feedrate specified by the F code in the loaded
machining file, but use the feed speed set in the
system.
Yes: Valid
No: Invalid
Use Default Spindle
Speed
When it is set as ―Yes‖, the system will not adopt
spindle speed specified by the S code in the
loaded machining file, but use the spindle speed
set in the system.
Yes: Valid
No: Invalid
Z Deceleration
Distance
To protect tools, the machine tool will decelerate
(at [approach speed]) when approaching the
target position during positioning. This
parameter is used to specify the distance from
the decelerating position to the target position.
0~999 (mm)
Z Approach Speed
It is the feed speed when the distance between
the tool and the workpiece is smaller than
―deceleration distance‖ during positioning.
0~Default Feedrate
(mm/min)
MAX Axial Velocity
(X)
It specifies the max. allowable speed of X axis.
0~6000000 (mm/min)
MAX Axial Velocity
(Y)
It specifies the max. allowable speed of Y axis.
0~6000000 (mm/min)
MAX Axial Velocity (Z)
It specifies the max. allowable speed of Z axis.
Z Down Feedrate
Limitation~6000000
(mm/min)
Limit Max Velocity for
small line
When it is set as ―Yes‖, the system will eliminate
the fluctuation of speed when machining short
line segments.
Yes: Valid
No: Invalid
Length for Limit Max
Velocity
Short line segments shorter than the value of
this parameter will be treated with velocity
smoothing.
0.001~100000 (mm)
Parameter ―startup speed‖ aims at the startup frequency of stepping & servo driver, and in driver
this parameter should be set zero. The startup speed refers to the highest frequency of direct
working startup without acceleration of motor.
