Window Master FlexiSmoke WSC 520 - Core System Modules; WSA 5 PS power supply module

10
Type of motor
Max. total 20A per section
WSA 5PS-module
1 x 20A-motor line
±24V
WSA 5SM-module
4 x 10A-motor lines ±24V
WSA 5ML-module
4 x 10A-motor lines MotorLink
®
Motors per
motor line
Motors per
module
Motors per
motor line
Motors per
module
WMU 885-1
4
2
4
2
4
WMU 885-2
4
2
4
2
4
WMU 885-3
3
0
0
0
0
WMU 885-4
4
0
0
0
0
WMU 895-1
4
2
4
2
4
WMU 895-2
4
2
4
2
4
WMU 895-3
3
0
0
0
0
WMU 895-4
4
0
0
0
0
WMX 503, 504, 523, 526-1
40
20
40
4
16
WMX 503, 504, 523, 526-2
40
20
40
2
8
WMX 503, 504, 523, 526-3
39
18
39
3
12
WMX 503, 504, 523, 526-4
40
20
40
4
16
WMX 803, 804, 813, 814,
823, 826-1
20
10
20
4
16
WMX 803, 804, 813, 814,
823, 826-2
20
10
20
2
8
WMX 803, 804, 813, 814,
823, 826-3
18
9
18
3
12
WMX 803, 804, 813, 814,
823, 826-4
20
8
20
4
16
WMD-1
20
10
20
4
16
WMD-2
20
10
20
2
8
WMD-3
18
9
18
3
12
WMD-4
20
8
20
4
16
WML 820/825
20
10
20
0
0
WML 860
20
10
20
4
16
WMB 801/802*
max. 4A connected to the
WMB
max. 4A connected to the WMB
0
0
WMB 811/812 */**
20
10
20
2
8
WMB 01M*/**
0
0
0
2
8
* Do not exceed the total power consumption of the motor line
** When having two locking motors per motor line, it must be one of each type: 1 x WMB 811 and 1 x WMB 812
*** The service input on the WMB 01M is ignored and can therefore not be used. When having two locking motors per motor line, it must be
one of each type: 1 x WMB 01M and 1 x WMB 02M.
4 Modules, accessories, spare parts
Modules
Power supply module 20A with 1 pcs. end of line module WSA 510
WSA 5PS
Overall control module without field bus interface
WSA 5MC NCO
Overall control module with field bus interface for KNX/BACnet-IP
WSA 5MC KNX
Input/output module
WSA 5IO
Motor module for ±24V standard motors with 4 pcs. end of line module WSA 510
WSA 5SM
Motor module for MotorLink
®
motors
WSA 5ML
Motor module for Renson
®
motors
WSA 5S5
