7
3 Variants of panels
Item composing
Size of the smoke ventilation panel
WSC 5??
?
?
?
?
E1
20A = WSC 520, 40A = WSC 540, 60A = WSC 560
WSC 5??
Selection of modules
The four modules listed below must be defined for each 20A section -
WSC 520 has one section, WSC 540 has two sections and WSC 560
has three sections.
Select module: Overall control module
WSA 5MC NCO – without field bus interface
0
WSA 5MC KNX – with field bus interface for KNX/BACnet IP
K
Select modules: Expansion modules
First expansion module (slot 3, the first free slot in the section)
No module
0
WSA 5IO – input-/output-module *
I
WSA 5SM – motor module for ±24V standard motors
S
WSA 5ML – motor module for motors with MotorLink
®
M
Second expansion module (slot 4, the second free slot in the section)
No module
0
WSA 5IO – input-/output-module *
I
WSA 5SM – motor module for ±24V standard motors
S
WSA 5ML – motor module for motors with MotorLink
®
M
Third expansion module (slot 5, the third free slot in the section)
No module
0
WSA 5IO – input-/output-module *
I
WSA 5SM – motor module for ±24V standard motors
S
WSA 5ML – motor module for motors with MotorLink
®
M
Certification / Product version number
E = EN 12101-10
E
1 = product version number
1
* Module position
The IO module is inserted in slot 3 and if further IO modules are added, the IO module is inserted before the motor
module.
MotorLink
®
motor module is inserted before the ±24V Standard motor module.
