Accessories
Back-up battery 18Ah (2 x WSA 017 per 20A-section)
WSA 017
FlexiSmoke™ break glass unit, primary, with data communication, plastic housing. Optional
connection to ventilation keypad and smoke detector (only 1 per line).
(x=colour of the housing: 1=red, 2=yellow, 3=grey, 4=blue, 5=orange)
WSK 501 000x
FlexiSmoke™ break glass unit, primary, with data communication, metal housing. Optional
connection to ventilation keypad and smoke detector (only 1 per line).
(x=colour of the housing: 2=yellow, 3=grey, 5=orange)
WSK 502 000x
FlexiSmoke™ break glass unit, primary, with data communication, plastic housing. Not
possible to connect ventilation keypad and smoke detector.
(x=colour of the housing: 1=red, 2=yellow, 3=grey, 4=blue, 5=orange)
WSK 503 000x
FlexiSmoke™ break glass unit, primary, with data communication, metal housing. Not
possible to connect ventilation keypad and smoke detector.
(x=colour of the housing: 2=yellow, 3=grey, 5=orange)
WSK 504 000x
Fireman override switch
WSK 601
Smoke detector
WSA 300
Rain sensor
WLA 331
Rain/wind sensor
WLA 330
Rain/wind sensor, with pulse output
WLA 340
Wind speed sensor
WOW 201
Wind direction sensor
WOW 202
Bracket for junction box
WOW 203
Junction box for WOW 201 and WOW 202
WOW 204
End of line motor module, 10 pcs.
WSA 510
10kΩ resistance, 10 pcs.
WSA 501
Fire alarm system module
WSA 306
Cable for CAN connection, 2x2x0,5mm², sold in hole meters
WLL 501
Cable for wind and rain sensor WLA 340, 4m UV-resistant cable 4 x 2 x 0,75mm2
WLL 604
Cables for comfort ventilation – see separate data sheet for further information
WLL 7xx
Cables for smoke ventilation – see separate data sheet for further information
WLL 8xx
Spare parts
Touch screen for WSA 5PS module
WSA 5LD
Back plane for modules, with top and bottom plate
WSA 5BP
Micro SD card for FlexiSmoke™, special industrial grade
WSA 502
Safety lock incl. 2 keys for smoke ventilation panel housing
WSA 438
Spare key for smoke panel, 1 pcs.
WSA 439
Plugs: 2 pcs. 6-pin plugs for CAN bus and 2 pcs. 3-pin plugs for break glass units
WSA 540
Replacement glass for break glass units type WSK 501, 5 pcs.
WSK 397
Keys for break glass units type 501 / 503, 5 pcs.
WSK 398
Keys for break glass units type 502 / 504, 1 pcs.
WSK 453
Lockable replacement plastic housing for break glass unit
x=colour of the housing: 1 = red, 2 = yellow, 3 = grey, 4 = blue, 5 = orange
WSK 399 000x
5 Technical data
Technical data
Output current (nominal)
WSC 520: 20A / WSC 540: 40A / WSC 560: 60A
Actuator secondary voltage
Motor voltage 24V DC (±15%)
Open circuit voltage at 230V AC (no load) 27.6V DC @ 20°
Ripple at max load max. 6% (3.5Vpp)
Motor lines
Per 20A section
