Woodward MicroNet Simplex User Manual

Manual 26166V1 MicroNet Simplex & MicroNet Plus
Woodward 23
MicroNet Simplex
 MicroNet 12 or 6 I/O
Slot Chassis
 Single CPU for
simplex operation
 PowerPC CPU5200,
Pentium, or Motorola
x040 CPU options
 Simplex or
Redundant I/O
modules
 Simplex or
Redundant Power
M
icroNet Simplex (RTN, 2-rack)
FAN_2
FAN_1
FAN_3
CPU
3-Slot
Power
S
uppl
y
3-Slot
Power
Supply
MicroNet Simplex 12
- Main rack
- Single CPU_5200
FAN_2
FAN_1
FAN_3
RTN
A1
3-Slot
Power
S
uppl
y
3-Slot
Power
Supply
MicroNet Simplex 12
- Expansion rack
- Single RTN
RTN-1 and 2
MicroNet Simplex (RTN, 3-rack)
FAN_2
FAN_1
FAN_3
CPU
A1
3-Slot
Power
Supply
3-Slot
Power
Supply
MicroNet Simplex 12
- Main rack
- Single CPU_5200
FAN_2
FAN_1
FAN_3
RTN
A1
3-Slot
Power
Supply
3-Slot
Power
Supply
MicroNet Simplex 12
- Expansion rack
- Single RTN
FAN_3 FAN_4
FAN_2FAN_1
PS
1
A1
3-Slot
Power
Supply
3-Slot
Power
Supply
RTN
A1
MicroNet
Simplex 6
- Exp
- RTN
RTN1
SW
RTN2
SW
MicroNet Simplex (copper XC
V
FAN_2
FAN_1
FA
N
RMT XCVR
A1
3-Slot
Power
Supply
3-Slot
Power
Supply
MicroNet Simple
x
- Expansion rack
- Single XCVR
FAN_3 FAN_4
FAN_2FAN_1
PS
1
A1
3-Slot
Power
Supply
3-Slot
Power
Supply
RMT XCVR
A1
MicroNet
Simplex 6
- Exp
- XCVR
XCVR
TBOX
FAN_2
FAN_1
FA
N
CPU
A1
3-Slot
Power
Supply
3-Slot
Power
Supply
MicroNet Simp
l
- Main rack
- Single CPU Pe
or Motorola x0
4
MAIN XCVR
Figure 3-1. MicroNet Simplex System Diagrams
3.1.1—Single CPU Options
The MicroNet Simplex control system offers a single CPU module that must be located in slot A1 of the
main chassis. Different CPU options may be selected to run the system.
 The CPU5200 module offers high processing capability in a PowerPC MPC5200 processor with features
like dual Ethernet, dual Real Time Network ports, dual CAN, and a configurable RS-232/RS-422/RS-485
serial port. Module operating temperature limits are –40 to +85 °C.
 The Pentium CPU module offers high processing capability with single Ethernet and dual RS-232 serial
ports. The Pentium CPU operating temperature limits are 0 to 50 °C.
 The Motorola 68040 CPU module offers basic capability and one RS-232 serial port.
3.1.2—Redundant Power Supplies
Two load sharing power supplies provide redundant power to the motherboard, CPU and I/O modules. The
chassis consists of three sections where the 1
st
section is reserved for either (1) or (2) power supplies. The
MicroNet Simplex power supplies are 3-slot wide each and are located together at the left side of the
chassis.
