Woodward MicroNet Simplex User Manual

Manual 26166V1 MicroNet Simplex & MicroNet Plus
Woodward 7
Personal Protective
Equipment
The products described in this publication may present risks that
could lead to personal injury, loss of life, or property damage.
Always wear the appropriate personal protective equipment (PPE) for
the job at hand. Equipment that should be considered includes but is
not limited to:
 Eye Protection
 Hearing Protection
 Hard Hat
 Gloves
 Safety Boots
 Respirator
Always read the proper Material Safety Data Sheet (MSDS) for any
working fluid(s) and comply with recommended safety equipment.
Start-up
Be prepared to make an emergency shutdown when starting the
engine, turbine, or other type of prime mover, to protect against
runaway or overspeed with possible personal injury, loss of life, or
property damage.
Electrostatic Discharge Awareness
Electrostatic
Precautions
Electronic controls contain static-sensitive parts. Observe the
following precautions to prevent damage to these parts:
 Discharge body static before handling the control (with power to
the control turned off, contact a grounded surface and maintain
contact while handling the control).
 Avoid all plastic, vinyl, and Styrofoam (except antistatic
versions) around printed circuit boards.
 Do not touch the components or conductors on a printed circuit
board with your hands or with conductive devices.
To prevent damage to electronic components caused by improper
handling, read and observe the precautions in Woodward manual
82715 , Guide for Handling and Protection of Electronic Controls,
Printed Circuit Boards, and Modules.
Follow these precautions when working with or near the control.
1. Avoid the build-up of static electricity on your body by not wearing clothing made of synthetic
materials. Wear cotton or cotton-blend materials as much as possible because these do not store
static electric charges as much as synthetics.
2. Do not remove the printed circuit board (PCB) from the control cabinet unless absolutely necessary.
If you must remove the PCB from the control cabinet, follow these precautions:
 Do not touch any part of the PCB except the edges.
 Do not touch the electrical conductors, the connectors, or the components with conductive
devices or with your hands.
 When replacing a PCB, keep the new PCB in the plastic antistatic protective bag it comes in
until you are ready to install it. Immediately after removing the old PCB from the control cabinet,
place it in the antistatic protective bag.
External wiring connections for reverse-acting controls are identical
to those for direct-acting controls.
Released

Woodward MicroNet Simplex Specifications

General

Brand	Woodward
Model	MicroNet Simplex
Category	Controller
Language	English
