CI6X SERIES SPECTROPHOTOMETER
16
Main Screen Menu
When the instrument is powered-up, the main (top level) screen appears after the diagnostics
test is complete. The main screen consists of the header bar and operation modes. The operation
modes are selected by using the navigation buttons located to the side of the display screen.
Measure Mode
The measure mode is the main mode of operation. Use the Measure mode to take and analyze
measurements, and select measurement options. Refer to the Measurement Mode section for
information.
Job Mode (Ci64/Ci64UV only)
The job mode is used to select and run downloaded jobs. Refer to the Job Mode section for
information.
Calibration Mode
The calibration mode is used to perform white reference and black trap calibrations. Refer to the
Calibration Mode section for information.
Configuration Mode
The configuration mode is used to set and edit the instruments configuration options. The
configuration options should be set before you use your instrument for the first time. Refer to the
Configuration Mode section for information.
Display Screen Layout
The display screen is divided into five main areas.
Measure mode
Calibration mode
Header bar
Main column
View column
Content area
Progress column
Job mode (Ci64/Ci64UV only)
Configuration mode
