CI6X SERIES SPECTROPHOTOMETER
28
9. Press the instrument firmly to the shoe and hold steady until the display indicates that the
reading is complete. Release the instrument.
10. Tap the Select control to save the calibration and exit to the main menu.
11. Store the calibration reference in a dry, dust free area, away from direct exposure to light.
NOTE: If an error message appears during or after white calibration, tap the Select control to
clear the message and try measuring the white reference again. If an error still occurs, clean
the white calibration reference as explained in the Appendices.
UV Calibration Procedure (Ci64UV only)
NOTE: Before performing the UV calibration, the Lamp Mode, Calibration Target Value, UV Type, and
Whiteness Timeout options must be set in the Configuration mode.
1. From the Main screen, use the Navigation control to move the highlight square to the
Calibration icon.
2. Tap the Select control to access the calibration screen.
3. Use the Up/Down navigation control to highlight “UV Calibration”.
4. Use the Right navigation control to move the highlight focus to the Progress column. Use the
Down navigation control to highlight the Next arrow icon (
→) if not highlighted and tap the
Select button.
5. Remove the protective cap from the white ceramic plaque in the calibration reference.
6. Position the instrument target window over the white ceramic plaque.
7. Press the instrument firmly to the shoe and hold steady until the display indicates that the
reading is complete. Release the instrument.
8. Reinstall the protective cap on the white ceramic plaque.
