CI6X SERIES SPECTROPHOTOMETER
24
UV Calibration Target Value (Ci64UV only)
This option is used to set the UV whiteness value of the UV calibration plaque. The value is
initially set at the factory. The value displayed here must match the value shown on the UV
calibration plaque used.
This icon only appears if the Lamp Mode is set to UV Included.
UV Type (Ci64UV only)
This option is used to select which “Whiteness Calibration” the instrument will use. The
D65 setting is used to select the calibration that comes with the instrument from the factory (UV
enhanced plastic calibration tile). The Adj1 and Adj2 options allow you to set up custom
calibrations. For example, a customer may calibrate to their own calibration tile or a UV enhanced
fabric; by selecting Adj1 or Adj2, the user can now have multiple UV calibrations on the
instrument. The available options are UV D65 (default), UV ADj1, and UV ADj2.
This icon only appears if the Lamp Mode is set to UV Included.
Whiteness Timeout (Ci64UV only)
This option is used to set the amount of time that elapses before a UV whiteness calibration
is required. The available settings are: Disabled, 8 days, 16 days, 32 days (default), and 64 days.
This icon only appears if the Lamp Mode is set to UV Included.
Language
This option is used to set the language that is displayed on the instrument. The available
settings are English (default), German, French, Spanish, Italian, Portuguese, Chinese Simplified,
Chinese Traditional, Korean, and Japanese.
Instrument Orientation
This option is used to change the display direction to accommodate both right and left
handed users. The available settings are Right Handed (default) and Left Handed.
Default Tolerance
This option is used to edit the parameters for the default tolerance.
NOTE: Refer to the Editing Standard Tolerances section later in this manual for the procedure on
editing the tolerances.
Date Format
This option is used to adjust the date format the instrument uses. The available settings
are: MM/DD/YYYY (default), DD/MM/YYYY, DD.MM.YYYY, YYYY/MM/DD, and YYYY-MM-DD.
NOTE: The date format automatically changes to the correct format for the selected language. If
desired, you can change the format after selecting the language.
