2Machine Connection

6 Xerox Phaser 3635 System Administration Guide

Rear View

Interface Ports

Front

USB 2.0 Port

This port is provided for connection to a USB flash drive and is used as an input port for

printing jobs, storing jobs and performing a software upgrade.

Power Switch

Power Connection

Card Reader Slot for

Feature Enablement Key

Foreign Device

Interface Port

Phone Port

Ext. Port

A Type USB Port

Ethernet Port
