Xerox Color 550/560 Printer
User Guide
188
Co
pying
Delete Outside/Delete Inside
This feature allows you to delete everything inside or outside a specified rectangular area. Up to three areas can be
defined for deletion.
To select areas to delete:
Touch Copy on the touch screen, then touch the Job Assembly tab.1.
Touch Delete Outside/Delete Inside.
2.
To delete everything outside the specified area when copying:
3.
Touch Delete Outside.
The area is defined by the rectangle formed between the points as shown on the touch screen. Touch
Area 1, then touch each coordinate on the touch screen. Use the alphanumeric keypad on the control
panel to enter the coordinate values for X1, X2, Y1 and Y2. When all values have been entered, touch
Save.
To apply the deleted area for 2-Sided copying, under Originals touch Both Sides, Side 1 Only or Side 2
Only.
Touch Save.
Additional areas can be defined by selecting Area 2 and Area 3.
