Maintenance
Xerox Color 550/560 Printer
User Guide
263
Replacing the Fuser
Make sure the machine has stopped running, and open the Front Door.1.
Grasp Handle #2 and turn it to the unlocked position.
2.
WARNING:
To avoid burns wait at least 5-10 minutes after powering off the printer to allow the fuser to cool down,
and observe warning labels inside.
Carefully pull out the Transfer Module.3.
This procedure shows you how to remove a used Fuser and replace it with a new Fuser. The machine will tell you
when you need to install a new one. The Fuser can be recycled so please follow the disposal instructions you receive
with the new cartridge.
