Xerox Phaser 3100MFP Service Manual

Parts List
Phaser 3100 MFP 04/08 5-17
PL 8 Automatic Document Feeder (3100MFP/X only) (2 of 3)
ITEM No. REFERENCE DESCRIPTION QTY R
1 Not spared ADF slider left D7N coloré
Left document guide
1 REP 10
2 Not spared ADF slider right D7N coloré
Right document guide
1 REP 10
3 Not spared Palier quart de tour rouleau coloré
Roller bearing
3
4 Not spared Vis autotartête large pour plast. 3X8
3X8 self tapping screw large for plastic
6
5 Not spared Guide papier supérieur assemblé
Upper paper guide assembly
1 REP 7
6 019N00958 Kit déliasseur pour LFx
Retard pad assembly
1 REP 5
7 Not spared Introducteur papier deflect colorée
Paper input guide
1 REP 6
8 Not spared Pignon 38 dents coloré
38 teeth analysis roller gear colored
2
9 007N01602 Pignon 27-33 dents coloré
27-33 teeth gear colored
1
10 001N00501 Support moteur assemblé
Motor frame assembly
1 REP 22
11 007N01603 Pignon 16-51 dents coloré
16-51 teeth gear colored
1
12 007N01604 Pignon 42 dents coloré
42 teeth gear colored
2
13 Not spared Photo interupter opic GP1A73A sp
Sensor
1
14 Not spared Rondelles M3X0,6
Washer M3X0.6
2
15 Not spared Chargeur assemble
Feeder assembly
1 REP 4
