Xerox Phaser 3100MFP Service Manual

General Procedures and Information
Phaser 3100 MFP 04/08 6-11
Component Characteristics
Control Panel PWB
The control panel PWB interfaces with the keyboard keys and the LCD display.The LCD has its
own driver in COB (Chip On Board).The card also has an external connector to the smart card
which is managed by the CPU.
SMS Communication (3100MFP/X only)
Transmission Yes (V23)
Reception No
Mailing 10 directly 249 from directory
DECT Telephone Communication (option)
(3100MFP/X only)
Wireless DECT Telephone Yes (via USB dongle)
SMS No
Network notification No
Answering device No
Directory (3100MFP/X only)
Capacity 250
Type Name / PSTN and SMS number
Transmission list 32
Transmission list capacity 249
Alphabetical typing Yes
Associated key Yes
Import/export directory on PC XML, EAB and CSV formats
Save directory on PC XML format
Geographical settings
Countries (3100MFP/X only) 25
Network (3100MFP/X only) TBR21, FCC68 depending on model
Languages 17

Xerox Phaser 3100MFP Specifications

General

Print Technology	Laser
Copy Resolution	600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	50 sheets
Connectivity	USB 2.0
Functions	Print, Copy, Scan
Duplex Printing	Manual
Paper Capacity	250 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Print Resolution	1200 x 1200 dpi
Scan Resolution	600 x 600 dpi
Copy Speed (Black)	20 cpm
Print Speed	Up to 20 ppm
