Xerox Phaser 3100MFP Service Manual

General Procedures and Information
6-36 04/08 Phaser 3100 MFP
Soft-switch 10: Communications: Locks/Miscellaneous (3100MFP/X only)
Soft-switch 18: Coding/UART Rate (3100MFP/X only)
Bit Value Description
1 0 SOS-AFFVIT: Communication rate display
Values:
0 (Without) the page number is displayed.
1 (With) the comm. rate is displayed.
2 1 SOS-BTYPNUM: Access to impulse/DTMF parameter
Values:
0 (With) Reserved
1 (Without)
3 0 Reserved
4 1 Reserved
5 1 SOS-TLRFAX: Remote readout by fax (ATTENTION!!!)
Values:
0 (Remote readout to Quadrige in transparent mode)
1 (Remote readout by fax)
6 0 Reserved
7 0 SOS-SONREA: Access to redialing parameters (screen /printer)
Values:
0 (No access)
1 (With access)
8 0 Reserved
Bit Value Description
1 1 SOS-CODMEM: Stored document encoding type
Values:
00 (MMR Coding)
01 (MH Coding)
10 (MR Coding)
11 (JBIG Coding)
2 1
3 1 SOS-CODCOM: COM negotiated encoding type
Values:
01 (MH Coding)
10 (MR Coding)
11 (MMR Coding)
4 1
5 0 Reserved
6 0
7 0 SOS-AFF_VIT_REELLE: Show/hide real communication rates
Values:
0 (show reduced rates)
1 (show real rates)
8 0 Reserved

Xerox Phaser 3100MFP Specifications

General

Print Technology	Laser
Copy Resolution	600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	50 sheets
Connectivity	USB 2.0
Functions	Print, Copy, Scan
Duplex Printing	Manual
Paper Capacity	250 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Print Resolution	1200 x 1200 dpi
Scan Resolution	600 x 600 dpi
Copy Speed (Black)	20 cpm
Print Speed	Up to 20 ppm
