Repairs and Adjustments
4-4 04/08 Phaser 3100 MFP
3. Disconnect the ribbon cable from the control panel board, Figure 2.
Figure 2
4. Remove the control panel.
Replacement
1. Replacement is the reverse of the removal procedure.
