Repairs and Adjustments
4-60 04/08 Phaser 3100 MFP
Replacement
1. Replacement is the reverse of the removal procedure.
2. When reassembling, ensure to set the positioning pin in the hole, Figure 2.
Figure 2
Positioning pin
