Repairs and Adjustments
Phaser 3435 5/08 4-27
5. The connectors are located, as shown below.
Figure 4
LED OPE
LCD OPE
Cartridge
LSU
Thermistor
MPF SEN
MPF
REGI
Pick up
LSU S/W
BLDC
Duplex
USB
Line
Engine
