Image Quality
Phaser 3435 5/08 3-25
White Black spot • Light or dark black
dots on the image
occur periodically. •
White spots occur in
the image periodi-
cally.
1. If light or dark periodical
black dots occur, this is
because the print cartridge
rollers are contaminated with
foreign substance or paper
particles.
(1)38mm interval: Charged
roller
(2)95mm interval: OPC cycle
2. If white spots occur in a
black image at intervals of
95mm, or black spots occur
elsewhere, the OPC drum is
damaged or foreign sub-
stance is stuck to the surface.
3. If a black and white or
graphic image is partially bro-
ken at irregular intervals, the
transfer roller's life has been
expired or the transfer voltage
is abnormal.
1. In case of 1 above -Run OPC
Cleaning Mode Print 4-5 times
repeatedly to remove, refer to
GP 5
. Especially check foreign
substance on the OPC surface,
then remove them with a clean
gauze moistened with IPA (Iso-
propyl Alcohol) not to damage
OPC if necessary. Never use
usual alcohol.
2. In case of 2 If they are not
disappeared by running OPC
Cleaning Mode Print 4-5 times.:
at intervals of 38mm -Replace
the print cartridge.: at intervals
of 95mm - Remove foreign sub-
stance.: Broken image -Replace
the print cartridge according to
carelessness.
3. In case of 3 -Exchange the
transfer roller because the life of
the transfer roller in use has
been expired. (Check the trans-
fer voltage and readjust if differ-
ent.)
Recycled product • Poor appearance
of the print cartridge.
• Unclean and rough
printouts. • Bad
background in the
image.
1. Poor appearance of the
print cartridge.
(1)Check the damage to label
and whether different materi-
als are used.
(2)Check the appearance of
parts of the print cartridge,
such as frame, hopper.
2. Unclean and rough print-
outs.
(1)Check whether foreign
substance or toner are stuck
to the terminal (contact point)
of the print cartridge.
(2)Check whether the state of
the terminal assembly is nor-
mal.
1. In case of 1
(1)If there is an evidence of dis-
assembling the print cartridge.
(2)If materials other than normal
parts of the print cartridge are
added or substituted.
2. In case of 2 -If there are any
abnormality in connection with
the situation of 1.
(1)It occurs when the print car-
tridge is recycled over 2 times.
(2)If toner nearly being expired
are collected to use, it is judged
as the recycled print cartridge.
Table 1:
Fault Signs Cause & Check Solution
