Xerox WorkCentre 4150 Service Manual

January 2016
6-32
WorkCentre WorkCentre 4150/4250/4260WorkCentre 4150/4250/
GP 7
General Procedures and Information
The environment acronyms are as follows:
• LL - Low temperature/low humidity.
• NN - Normal temperature/normal humidity.
• HH - High temperature/high humidity.
4265 Specifications
Refer to the following tables for the 4265 specifications:
• Table 19 General Specifications.
• Table 20 Fax Specifications.
• Table 21 Scanner Specifications.
• Table 22 Copy Specifications.
• Table 23 Telephone Specifications.
• Table 24 Consumables
• Table 25 Fuser Operating Temperatures
• Table 26 HVPS Output
Table 12 Scanner specifications
Item Description
Type Flatbed (with DADF)
Device Color CCD (Charge Coupled Device) Module
Interface IEEE1284 (ECP Support) USB (without HUB Mode)
Compatibility Scan to USB, direct connect TWAIN
Optical Resolution (H X V) 600 x 600 dpi
Halftone 256 Levels
Effective Scan width 208 mm (8.2 inches)
Table 13 Copy specifications
Item Description
Mode B/W
Quality Text/Photo/Mixed
Copy Speed 55ppm for 8.5 x 11, 53ppm for A4
Optical Resolution (H x V) 600 x 600 dpi
Multi Copy 1 to 999
Maximum Original Size Legal
Maximum Page Size Legal
Paper Type Selection Plain, Cardstock, Transparency, Bond, Labels, Colored
Zoom Range Platen: 25-400% (1% Step) DADF: 25-100% (1% Step)
Table 14 Telephone specifications
Item Description
Speed Dial 200 Locations
Tone/Pulse Tone only user mode. Tone/Pulse selectable in tech mode.
Ringer Volume Off, low, medium, high
Chain Dial None
Pause Yes, using the Pause/Redial Key
Table 15 Consumables
Item Life expectancy
Toner cartridge 23K prints (12K starter toner cartridge) (5% coverage pattern)
Xerographic module 80K prints (simplex normal mode)
Table 16 Fuser operating temperatures
Machine State or
Paper Type
Environment (Power on/after 50 prints/after 150 prints)
LL NN HH
Machine in standby 175 deg. C 175 deg. C 170 deg. C
Plain 189/189/185 deg. C 189/185/185 deg. C 184/184/184 deg. C
Thick/Bond/Label 199/195/195 deg. C 199/195/195 deg. C 194/190/190 deg. C
Thin 180/180/175 deg. C 180/180/175 deg. C 175/170/170 deg. C
Envelope 199/195/195 deg. C 199/195/195 deg. C 194/190/190 deg. C
Cardstock 199/195/195 deg. C 199/195/195 deg. C 194/190/190 deg. C
OHP 175/170/165 deg. C 175/170/165 deg. C 175/170/165 deg. C
Table 17 HVPS Output
HVPS Output Voltage
Transfer High Voltage (THV) Max +5000V DC +/-5%
Charge Voltage (MHV) -1100V to -1800V DC +/-5%
Developing Voltage (DEV) -450V to -600V DC +/-5%
Detack Voltage -3000 to +3000V DC +/-5%
Fuser Bias 0 to +1000V DC +/-5%
Table 18 Finisher specifications
Item Description
Stacking capacity 500 sheets
Stapling capacity 50 sheets
Staple cartridge capacity 5000 staples
Weight 10.5Kg (23lb)
Dimension with stacker tray (W x D x H) 726 x 390 x 300mm (28.5 x 15.3 x 11.8 inches)
Input power (from IOT) +24V, +5V and +3.3V
Table 16 Fuser operating temperatures
Machine State or
Paper Type
Environment (Power on/after 50 prints/after 150 prints)
LL NN HH
