Xerox WorkCentre 4150 Service Manual

January 2016
6-70
WorkCentre 4150/4250/4260WorkCentre 4150/4250/4260WorkCentre Work-
dC330
General Procedures and Information
Output Codes
Table 11 Output codes 04
Code Displayed Name Description General
04-100 Main BLDC Motor Energizes the main BLDC motor (MOT04-
100). Use in conjunction with 04-110.
On/Off.
04-120
(4265)
Main Fan Energizes the Main Fan. On/Off
04-200 Exit Motor Forward Fast Energizes the exit motor (MOT04-200) for-
ward fast.
On/Off.
04-210 Exit Motor Forward Slow Energizes the exit motor (MOT04-200) for-
ward slowly.
On/Off.
04-220
(4265)
Exit Motor Reverse Energizes the Exit Motor in reverse. On/Off
04-230 Duplex Motor Forward Energizes the duplex motor (MOT04-300) for-
ward.
On/Off.
04-310 Duplex Motor Backward Energizes the duplex motor (MOT04-300)
backwards.
On/Off.
04-400 Duplex Fan Run Energizes the duplex fan. On/Off.
04-510 T1 Elevating Motor Energizes the tray 1 elevator motor (MOT04-
510) up.
On/Off.
04-520 T2 Elevating Motor Energizes the tray 2 elevator motor (MOT04-
250) up.
On/Off.
04-530 T3 Elevating Motor Energizes the tray 3 elevator motor (MOT04-
530) up.
On/Off.
04-540 T4 Elevating Motor Energizes the tray 4 elevator motor (MOT04-
540) up.
On/Off.
Table 12 Output codes 05
Code Displayed Name Description General
05-200 DADF Scan Motor
Forward
Energizes the DADF scan motor
(MOT05-200).
On/Off.
05-201 DADF Scan Motor
Reverse
Energizes the DADF Scan Motor
(MOT05-200) in reverse.
On/Off
05-210 DADF Duplex Motor
Forward
Energizes the DADF duplex motor
(MOT05-210) forward.
On/Off.
05-220 DADF Duplex Motor
Backward
Energizes the DADF duplex motor
(MOT05-210) in reverse.
On/Off.
05-300 DADF Pick-Up Clutch Energizes the DADF document pick-up
clutch (CL05-300).
On/Off.
05-310 DADF Regi. Clutch Energizes the DADF registration clutch
(CL05-310).
On/Off.
05-320
(4250/
4260)
DADF Lift Solenoid Energizes the DADF lift solenoid
(SOL05-320).
On/Off.
Table 13 Output codes 06
Code Displayed Name Description General
06-100 LSU Motor Run Energizes the LSU motor (MOT06-
100). Use in conjunction with 06-110.
On/Off.
06-200 LSU LD Power Switches on or off the LSU power sup-
ply.
On/Off.
06-300 LSU Fan Run Energizes the LSU fan. Use in conjunc-
tion with 06-310.
On/Off.
Table 14 Output codes 07
Code Displayed Name Description General
07-600
(4250/
4260)
Envelope Motor Energizes the envelope motor
(MOT07-600).
On/Off.
07-620
(4250/
4260)
ID Sensor Starts ID sensing. Use in conjunction
with 07-630.
On/Off.
Table 15 Output codes 08
Code Displayed Name Description General
08-800 Bypass Feed Solenoid
(Clutch)
Energizes the bypass tray feed clutch
(CL08-800).
On/Off.
08-810 T1 Pick-Up Solenoid
(Clutch)
Energizes the tray 1 pick up clutch
(CL08-810).
On/Off.
08-820 T2 Pick-Up Solenoid
Clutch
Energizes the tray 2 pick up clutch
(CL08-820).
On/Off.
08-830 T3 Pick-Up Clutch Energizes the tray 3 pick up clutch
(CL08-830).
On/Off.
08-840 T4 Pick-Up Clutch Energizes the tray 4 pick up clutch to
(CL08-840).
On/Off.
08-850 Registration Clutch Energizes the registration clutch
(CL08-850).
On/Off.
08-860 Duplex Feed Clutch Energizes the duplex feed clutch
(CL08-860).
On/Off.
08-870 Duplex Gate Solenoid Energizes the duplex gate solenoid
(SOL08-870).
On/Off.
08-920 T2 Feed Motor Run Energises the tray 2 feed motor
(MOT08-920).
On/Off.
08-930 T3 Feed Motor Run Energises the tray 3 feed motor
(MOT08-930).
On/Off.
08-940 T4 Feed Motor Run Energises the tray 4 feed motor
(MOT08-940).
On/Off.
