Xerox WorkCentre 5016/5020 User Guide 78
7Printing
This chapter describes the basic flow of a print job, starting from setting up the printer,
and the basic printing procedure.
Important • You must install the print driver in advance. For information on how to install the print
driver, refer to "Installing the Print Driver and the Scan Driver (TWAIN driver)" (P.34).
Setting Up the Printer
This section describes how to set up the printer preferences and how to specify the
custom paper size.
Setting the Printer Preferences
The following procedure describes how to specify the printer preferences.
1. Select [Start] at the bottom of the screen, then select [Printers and Faxes].
The [Printers and Faxes] dialog box appears.
2. Right-click on the [Xerox WorkCentre 5016], [Xerox WorkCentre 5020/B], or
[Xerox WorkCentre 5020/DB] printer, and select [Properties] from the displayed
pop-up menu.
Note • Because this procedure to open the [Properties] dialog box uses Windows XP as an
example, you may have to open the [Properties] dialog box in different ways,
depending on the operating system in use. Refer to a guide provided with the operating
system for more information.
The [Properties] dialog box appears.
3. Click [Printing Preferences].

Xerox WorkCentre 5020 Specifications

General

Print Technology	Laser
Print Speed	Up to 20 ppm
Print Resolution	Up to 600 x 600 dpi
Max Paper Size	A3
Standard Paper Capacity	250 sheets
Bypass Tray Capacity	100 sheets
Duplex Printing	Manual
Copy Speed	Up to 20 cpm
First Page Out Time (Copying)	Less than 10 seconds
Scan Resolution	Up to 600 x 600 dpi
Operating System Compatibility	Windows, Mac OS
Automatic Document Feeder	50 sheets
Connectivity	USB 2.0
Functions	Print, Copy
Reduction / Enlargement	25% - 400%
Scan Destinations	USB, Email
Fax Transmission Speed	33.6 kbps
First Page Out Time (Printing)	Less than 8 seconds
