Conventions
Xerox WorkCentre 5016/5020 User Guide 8
Conventions
This section describes the conventions that are used throughout this User Guide.
WARNING: indicates statements that alert you to the possibility of personal harm.
CAUTION: indicates statements that suggest the possibility of mechanical damages
as a result of an action.
Important: indicates important information that a user should be aware of.
Note: indicates additional information on operations or features.
" ": indicates cross-references within this guide and input text
[ ]: indicates the values and error codes appear in the Display, and also
indicates the names of menus, windows, dialog boxes, buttons, and other
items displayed on a computer monitor.
< >: indicates hardware buttons on the Control Panel of the machine and keys
on a computer keyboard.
This section also describes terms that are used throughout this User Guide.
• Orientation is used to mean the direction of images on the page.
• LEF (Long Edge Feed)
Loading documents and paper with one of the long edges to be fed into the machine
first.
• SEF (Short Edge Feed)
Loading documents and paper with one of the short edges to be fed into the machine
first.
• Paper is synonymous with media, and is used interchangeably.
• Machine is synonymous with Xerox WorkCentre 5016, 5020/B, 5020/DB, and is
used interchangeably.
• Computer refers to a personal computer or workstation.
• System Administrator refers to a person who is responsible for maintaining the
machine, such as setting up the machine, installing the print drivers, and managing
software.
Related Information Sources
The following sources of information are available for the machine:
•User Guide
• Installation Guide
• Quick Use Guide
Note • Please note that diagrams used in this User Guide apply to a fully configured machine and
therefore may not exactly represent the configuration being used.
LEF Orientation
Paper feed direction
SEF Orientation
Paper feed direction
To Next Page
