Xinje DS3 series servo User Manual

DS3 series servo manual
2
2. Type
1) Servo drive
DS3 – 2 1P8
Suitable motor capacity
0P7: 0.75KW, 1P5: 1.5KW, 1P8: 1.8KW, 2P7: 2.7KW
Voltage level: 2: 220V, 4: 380V
Servo series name: DS3: standard type
2) Servo motor
MS -110 ST - M 06030 A Z- 2 1P8
Power
Voltage level
Power-loss brake
Shaft
Feature code
Feedback part code
Sine drive motor
Base No.
Motor series name
Base No.: 60, 80, 110, 130;
Feedback part code: M (optical pulse encoder)
Feature code: first 3-bit means rated torque; last 2-bit means rated speed
00630: rated torque 0.6N·m, rate speed: 3000rpm
02430: rated torque 2.4N·m, rate speed: 3000rpm
06030: rated torque 6.0N·m, rate speed: 3000rpm
10015: rated torque 10.0N·m, rate speed: 1500rpm
Shaft type: A-no key, B-with key
Power-loss brake: vacant-no, Z-with DC99V power-loss brake
Voltage level: 2－220V, 4-380V
Power: 0P2-0.2KW; 0P4-0.4KW; 0P7-0.75KW; 1P5-1.5KW; 1P8－1.8KW
