DS3 series servo manual

Input signal state

Segment

Code

Explanation Modbus

address

Segment

Code

Explanation Modbus

address

LED4_0 /SPD-A internal

speed setting

0x0808 LED5_0 /S-ON servo signal 0x0800

LED4_1 /SPD-B internal

speed setting

0x0809 LED5_1 /P-CON proportional

action command

0x0801

LED4_2 /C-SEL control

mode

0x080A LED5_2 /P-OT forward

suppression

0x0802

LED4_3 /ZCLAMP zero

clamp

0x080B LED5_3 /N-OT reverse

suppression

0x0803

LED4_4 Vacant 0x080C LED5_4 /ALM-RST clear the

alarm

0x0804

LED4_5 /G-SEL gain switch 0x080D LED5_5 /P-CL forward external

torque limit

0x0805

LED4_6 /CLR clear the

pulse

0x080E LED5_6 /N-CL reverse external

torque limit

0x0806

LED5_7 /SPD-D internal speed

setting

0x0807

Output signal state

Segment

code

Explanation Modbus

address

Segment

code

Explanation Modbus

address

LED1_0 Near (/NEAR) 0x081A LED2_0 Position end

(/COIN)

0x0812

LED1_1 Alarm output

(/ALM)

0x081B LED2_1 Speed consistent

(/V-CMP)

0x0813

LED2_2 Rotation checking

(/TGON)

0x0814

LED2_3 Ready (/S-RDY) 0x0815

LED2_4 Torque limit (/CLT) 0x0816

LED2_5 Speed limit 0x0817
