4-5-4. Data block Move [BMOV]
1. Summary
Move the data block to other soft component
Data block move [BMOV]
16 bits
BMOV
32 bits
-
Execution
condition
Normally ON/OFF coil,
rising/falling edge
Suitable Models
XD, XL
Hardware
requirement
-
Software
requirement
-
2. Operands
Operands
Function
Data Type
S
Specify the source data block or soft component
address code
16 bits, BIN; bit
D
Specify the target soft components address code
16 bits, BIN; bit
n
Specify the move data’s number
16 bits, BIN;
3. Suitable soft components
*Notes: D includes D, HD; TD includes TD, HTD; CD includes CD, HCD, HSCD, HSD;
DM includes DM, DHM; DS includes DS, DHS.
M includes M, HM, SM; S includes S, HS; T includes T and HT; C includes C and HC.
Move the source data block to the target data block. The data quantity is n.
<word move>
<bit move>
BMOV D5 D10 K3
X0
n
S· D·
D5
D6
D7
D10
D11
D12
n=3
Operand
System
Constant
Module
D
*
FD
TD
*
CD
*
DX
DY
DM
*
DS
*
K /H
ID
QD
S
●
●
●
●
●
●
●
●
D
●
●
●
●
●
●
n
●
●
●
●
●
●
●
Word
Bit
Operand
System
X
Y
M
*
S
*
T
*
C
*
Dn.m
S
●
●
●
D
●
●
●
Description
