7. The final heating temperature will up to 70 degree when the overshoot is permitted. It is
over the target temperature by 10 degree, the overshoot amount is small.
8. To enlarge the PID calculation range can suppress the heating overshoot.
8 C Language Function Block
In this chapter, we focus on C language function block’s specifications, edition, instruction
calling, application points etc. We also attach the common function list.
8-1．Summary
XD, XL supports almost all C language function in XDPPro software (also supports global
variable). Users can call the function at many places and call different functions, which
greatly increase program security and programmer’s efficiency.
8-2．Instruction Format
1． Instruction Summary
Call the C language Function Block at the specified place.
Call the C language function block [NAME_C]
16 bits
instruction
NAME_C
32 bits
Instruction
-
Execution
condition
Normally ON/OFF,
Rising/Falling Edge activation
Suitable
Models
XD, XL
Hardware
Software
2． Operands
Operands
Function
Type
S1
Name of C Function Block, defined by the user
String
S2
Corresponding start ID of word W in C language
function
16 bits, BIN
S3
Corresponding start ID of word B in C language
function
bit, BIN
