Xinje XD5 User Manual

161
The source data and result address can be the same. Please note that when X0 is ON, the
instruction will be executed in every scanning period.
Note: the add value must be floating numbers, otherwise the result will be error.
4-9-4．Floating Subtraction [ESUB]
1. Summary
Floating Sub [ESUB]
16 bits
-
32 bits
ESUB
Execution
condition
Normally ON/OFF,
rising/falling edge
Suitable
Models
XD, XL
Hardware
requirement
-
Software
requirement
-
2. Operands
Operands
Function
Data Type
S1
Subtraction operation data address
32 bits, BIN
S2
Subtraction operation data address
32 bits, BIN
D
Result address
32 bits, BIN
3. Suitable soft components
*Notes: D includes D, HD; TD includes TD, HTD; CD includes CD, HCD, HSCD, HSD;
DM includes DM, DHM; DS includes DS, DHS.
ESUB D10 D20 D50
S1· S2· D·
X0
The binary floating value S1 subtract S2, the result is stored in the target address.
Operand
System
Constant
Module
D
*
FD
TD
*
CD
*
DX
DY
DM
*
DS
*
K /H
ID
QD
S1
●
●
●
●
●
●
●
S2
●
●
●
●
●
●
●
D
●
●
●
●
Word
Description
(D11, D10) － (D21,D20) → (D51,D50)
Binary Floating Binary Floating Binary Floating
