Xinje XD5 User Manual

272
definitions of specific parameters.
6-5-2． Write serial port parameters [CFGCW]
1. Instruction overview
Write the local specified register value to specific serial port.
Write serial port parameters [CFGCW]
16-bit
instruction
CFGCW
32-bit
instruction
-
Execution
condition
Normally ON/OFF, rising
edge triggering
Suitable
model
XD, XL
Hardware
-
Software
V3.4 and higher version
2. Operand
Operand
Function
Type
S1
Local register starting address
16-bit, BIN
S2
Write serial port parameters number
16-bit, BIN
S3
Serial port no.
16-bit, BIN
3. Suitable soft component
* Note: D denotes D HD; TD denotes TD HTD; CD denotes CD HCD HSCD HSD; DM
denotes DM DHM;
DS stands for DS DHS.
CFGCW HD0 K8 K2
X0
S2. S3.S1.
 Operator S2: The number of registers used to write serial parameters is generally 8
(XD5E/XDME series is 9).
 Operator S3: Serial port range: K0 ~ K5. K0: Port0, K1: Port1, K2: Port2 or Port2-
RS232 or Port2-RS485, K3: Port3, K4: Port4, K5: Port5.
 Write HD0~HD7 parameters to serial port 2. See sections 6-5-3 for the names and
definitions of specific parameters.
Word
operand
System
constant
Module
D
FD
ED
TD
CD
DX
DY
DM
DS
K /H
ID
QD
S1
●
S2
●
●
●
S3
●
●
Function and action
