Xinje XD5 User Manual

242
Notes: D includes D, HD; TD includes TD, HTD; CD includes CD, HCD, HSCD, HSD;
DM includes DM, DHM; DS includes DS, DHS. M includes M, HM, SM; S includes S
and HS; T includes T and HT; C includes C and HC.
COLW K1 K500 M1
X0
K2
D1· D2· S1· S2·
 Write single coil, Modbus function code is 05H.
 Serial port: K0~K5. K0: Port0 (RS232), K1: Port1(RS232), K2: Port2(RS485), K3:
Port3(left extension port), K4: Port4(above extension port 1), K5: Port5(above
extension port 2).
 When X0 is ON, COLW instruction is executed, Modbus read write flag SM160(serial
port2) is set ON, SM160 is set OFF when the execution is completed. If a
communication error occurs and the number of resend is set, it will be automatically
resend. Users can check the relevant registers to determine the cause of the error. The
execution result of Modbus read and write instructions of serial port 2 is in SD160.
Multiple coils write [MCLW]
Summary
Write local device multiple coils to remote station no’s coil.
Multiple coils write [MCLW]
16 bits
instruction
MCLW
32 bits
instruction
-
Execution
Condition
Normally ON/OFF, edge
triggering
Suitable
models
XD, XL
Hardware
Requirement
-
Software
Requirement
-
Operands
Operands
Function
Type
D1
Specify remote communication station number
16 bits，BIN
Function
Operand
System
X
Y
M*
S*
T*
C*
Dn.m
S1
●
●
●
●
●
●
Bit
