Xinje XD5 User Manual

147
*Notes: D includes D, HD; TD includes TD, HTD; CD includes CD, HCD, HSCD, HSD;
DM includes DM, DHM; DS includes DS, DHS.
HEX D200 D100 K4
S· D·
n
X0
Convert the high 8 bits and low 8 bits in source to HEX data. Move 4 bits every time
to destination . The convert character number is assigned by n.
The convert process is the following:
n=k4
0 1 0 0 0 0 0 1 0 0 1 1 0 0 0 0
D200
41H? [A] 30H? [0]
0 1 0 0 0 0 1 1 0 1 0 1 0 0 1 0
D201
43H? [C] 42H? [B]
0 0 0 0 1 0 1 0 1 0 1 1 1 1 0 0
D100
0 A B
C
4-8-8．Coding [DECO]
Summary
Change any data or bit to 1.
Coding [DECO]
16 bits
DECO
32 bits
-
Execution
condition
Normally ON/OFF,
rising/falling edge
Suitable
Models
XD, XL
Hardware
requirement
-
Software
requirement
-
Description
(S·)
ASCII
Code
HEX
Convert
D200 down
30H
0
D200 up
41H
A
D201 down
42H
B
D201 up
43H
C
D202 down
31H
1
D202 up
32H
2
D203 down
33H
3
D203 up
34H
4
D204 down
35H
5
n (D·)
D102
D101
D100
1
Not change to be
0
···0H
2
··0AH
3
·0ABH
4
0ABC
H
5
···0H
ABC1
H
6
··0AH
BC12H
7
·0ABH
C123H
8
0ABC
H
1234H
9
···0H
ABC1H
2345H
S·
D·
