Article Name Location Description
LED Front Display status of system, internal hard disk, USB device and so on.
FAN Rear
The fan is built to exhaust waste heat out of Xtreamer e-TRAYz. It
will start automatically when the server starts.
Copy Rear
Pressing the button will copy the data from the connected USB
device to the Xtreamer e-TRAYz’ internal HDD.
USB Port Rear
Xtreamer e-TRAYz offers 2 USB ports for adding additional external
hard drives, USB printers, USB wireless LAN or other USB devices.
Reset Rear
This is for the reset of Network setup.
When the power switch is turned on while Reset button is pressing
for 2~3 sec, a booting initialization is done. You need to boot this
way when you reinstall software replacing internal hard disk.
LAN Rear
The LAN port is where you connect RJ-4 cable to Xtreamer e-
TRAYz.
Power Port Rear The power port is where you connect the AC power adapter.
