13
LED
LED Color Status Description
Power/Access BLUE
Turned on Connected power
Blinking Data read and write at HDD
Turned off Disconnected power
HDD A/HDD B RED
Turned on Disconnected or abnormal status of HDD A/B
Turned off At normal status of HDD A/B
USB YELLOW
Cyclic Blinking Installing software or not installed the software
Non-Cyclic
Blinking
Data read and write at USB device
Network GREEN
Turned on Connected LAN cable normally
Turned Off Disconnected LAN cable
Button and Beep
Button/Beep Description
Copy
When the USB device is connected, this button is pressed for 1 sec and release, copy
starts from USB device to internal disk(External Disk – USB_copy) with a single beep.
During the copy, this button is pressed for 3 sec and released the copy stopped with
2 beep.
Reset
When this button is pressed for 3 sec, the network initialization is started with a
single beep and completed with 2 beeps.
When the power switch is turned on while Reset button is pressing for 2~3 sec, a
booting initialization is done.
Single Beep
When system booting is completed.
When system successfully recognizes the newly connected USB device.
When USB copy is started.
When the network initialization is started.
2 Beep
When USB copy is completed.
When USB copy is canceled.
When USB device is disconnected.
When the network initialization is completed.
