AGC SLOW DELAY
Function: Sets the AGC-SLOW DELAY voltage
decay characteristics for FM mode.
Available Values: 20 - 4000msec
Default Setting: 1500msec
Description: Sets the AGC voltage decay char-
acteristics in 20msec steps after the
input signal level becomes lower
than the AGC detection level and the
HOLD time has expired.
LCUT FREQ
Function: Sets the low-frequency cuto󰀨 audio l-
ter in FM mode.
Available Values: OFF / 100Hz - 1000Hz
Default Setting: 300
Description: The cutoff frequency can be set at
50Hz increments between 100Hz
and 1000Hz.
LCUT SLOPE
Function: Sets the slope of the low-frequency
cuto󰀨 audio lter in FM mode.
Available Values: 6dB/oct / 18dB/oct
Default Setting: 18dB/oct
HCUT FREQ
Function: Sets the high-frequency cutoff audio
lter in FM mode.
Available Values: 700Hz - 4000Hz/OFF
Default Setting: 3000Hz
Description: The cutoff frequency can be set at
50Hz increments between 700Hz
and 4000Hz.
HCUT SLOPE
Function: Sets the slope of the high-frequency
cuto󰀨 audio lter in FM mode.
Available Values: 6dB/oct / 18dB/oct
Default Setting: 18dB/oct
USB OUT LEVEL
Function: Sets the level of the receive FM signal
output from the USB jack.
Available Values: 0 - 100
Default Setting: 50
REAR OUT LEVEL
Function: Sets the level of the receive FM signal
output from the RTTY/DATA jack.
Available Values: 0 - 100
Default Setting: 50
MOD SOURCE
Function: Selects the transmit audio input jack in
the FM mode.
Available Values: MIC / USB / REAR / AUTO
Default Setting: AUTO
Description:
MIC: Audio is input from the MIC jack on the
front panel.
USB: Disables the microphone circuit on the
front panel and inputs audio/data from the
USB jack on the rear panel.
REAR: Disables the microphone circuit on the
front panel and inputs audio/data from the
RTTY/DATA jack on the rear panel.
AUTO: Modulation is automatically selected ac-
cording to the transmission method.
PTT: The MIC jack on the front panel.
MOX: The MIC jack on the front panel.
CAT: The USB jack on the rear panel.
DAKY: The RTTY/DATA jack on the rear
panel.
RTS: The USB jack on the rear panel.
DTR: The USB jack on the rear panel.
VOX: Terminal set with “VOX SELECT”.
USB MOD GAIN
Function: Sets the level of the FM signal input
when “MOD SOURCE” is set to “USB”.
Available Values: 0 - 100
Default Setting: 50
REAR MOD GAIN
Function: Sets the level of the FM signal in-
put when “MOD SOURCE” is set to
“REAR”.
Available Values: 0 - 100
Default Setting: 50
RPTT SELECT
Function: Sets the PTT control for the FM trans-
mit signal.
Available Values: OFF / RTS / DTR / DAKY
Default Setting: OFF
Description:
OFF: No PTT control.
RTS: Controls the FM transmit signal from the
USB virtual COM/RTS ports.
DTR: Controls the FM transmit signal from the
USB virtual COM/DTR ports.
DAKY: Controls the FM transmit signal from the
RTTY/DATA jack (pin 3) on the rear panel.
RPT SHIFT
Function: Sets the Repeater Shift Direction.
Available Values: - / SIMP / +
Default Setting: SIMP
Description:
-: Shifts to the lower frequency o󰀨set.
SIMP: The frequency does not shift.
+: Shifts to the higher frequency o󰀨set.
