NAR WIDTH
Function: Sets the IF BANDWIDTH of the digital
lter when the [NAR] key is pressed in
DATA mode.
Available Values: 50 / 100 / 150 / 200 / 250 / 300/
350 / 400 / 450 / 500 / 600 /
800 / 1200 / 1400 / 1700 /
2000 / 2400 / 3000 / 3200 /
3500 / 4000 (Hz)
Default Setting: 300Hz
PSK TONE
Function: Set the PSK tone
Available Values: 1000 / 1500 / 2000 (Hz)
Default Setting: 1000Hz
DATA SHIFT (SSB)
Function: Sets the carrier point in DATA mode.
Available Values: 0 - 3000 (Hz)
Default Setting: 1500Hz
Description: The frequency can be set in steps of
10Hz.
RADIO SETTING
- MODE RTTY -
AF TREBLE GAIN
Function: Sets the amount of gain in the treble
range of the received audio.
Available Values: -20 to +10
Default Setting: 0
Description: The amount of gain in the treble
range can be set in the range of -20
to +10.
AF MIDDLE TONE GAIN
Function: Setting the amount of gain in the mid-
dle range of the received audio.
Available Values: -20 to +10
Default Setting: 0
Description: The amount of gain in the middle
range can be set in the range of -20
to +10.
AF BASS GAIN
Function: Setting the amount of gain in the bass
range of the received audio.
Available Values: -20 to +10
Default Setting: 0
Description: The amount of gain in the bass
range can be set in the range of -20
to +10.
AGC FAST DELAY
Function: Sets the AGC-FAST DELAY voltage
decay characteristics for RTTY mode.
Available Values: 20 - 4000msec
Default Setting: 160msec
Description: Sets the AGC voltage decay char-
acteristics in 20msec steps after the
input signal level becomes lower
than the AGC detection level and the
HOLD time has expired.
AGC MID DELAY
Function: Sets the AGC-MID DELAY voltage de-
cay characteristics for RTTY mode.
Available Values: 20 - 4000msec
Default Setting: 500msec
Description: Sets the AGC voltage decay char-
acteristics in 20msec steps after the
input signal level becomes lower
than the AGC detection level and the
HOLD time has expired.
84
