AGC SLOW DELAY
Function: Sets the AGC-SLOW DELAY voltage
decay characteristics for PSK/DATA
mode.
Available Values: 20 - 4000msec
Default Setting: 1500msec
Description: Sets the AGC voltage decay char-
acteristics in 20msec steps after the
input signal level becomes lower
than the AGC detection level and the
HOLD time has expired.
LCUT FREQ
Function: Sets the low-frequency cuto󰀨 audio l-
ter in DATA mode.
Available Values: OFF / 100Hz - 1000Hz
Default Setting: 100
Description: The cutoff frequency can be set at
50Hz increments between 100Hz
and 1000Hz.
LCUT SLOPE
Function: Sets the slope of the low-frequency
cuto󰀨 audio lter in DATA mode.
Available Values: 6dB/oct / 18dB/oct
Default Setting: 18dB/oct
HCUT FREQ
Function: Sets the high-frequency cutoff audio
lter in DATA mode.
Available Values: 700Hz - 4000Hz / OFF
Default Setting: 3200Hz
Description: The cutoff frequency can be set at
50Hz increments between 700Hz
and 4000Hz.
HCUT SLOPE
Function: Sets the slope of the high-frequency
cuto󰀨 audio lter in DATA mode.
Available Values: 6dB/oct / 18dB/oct
Default Setting: 18dB/oct
USB OUT LEVEL
Function: Sets the level of the receive DATA sig-
nal output from the USB jack.
Available Values: 0 - 100
Default Setting: 50
REAR OUT LEVEL
Function: Sets the level of the receive DATA sig-
nal output from the RTTY/DATA jack.
Available Values: 0 - 100
Default Setting: 50
TX BPF SEL
Function: Selects the audio passband of the DSP
modulator on the DATA mode.
Available Values: 50-3050 / 100-2900 / 200-2800/
300-2700 / 400-2600 (Hz)
Default Setting: 50-3050 Hz
MOD SOURCE
Function: Selects the transmit audio input jack in
the DATA mode.
Available Values: MIC / USB / REAR / AUTO
Default Setting: AUTO
Description:
MIC: Audio is input from the MIC jack on the
front panel.
USB: Disables the microphone circuit on the
front panel and inputs audio/data from the
USB jack on the rear panel.
REAR: Disables the microphone circuit on the
front panel and inputs audio/data from the
RTTY/DATA jack on the rear panel.
AUTO: Modulation is automatically selected ac-
cording to the transmission method.
PTT: The MIC jack on the front panel.
MOX: The MIC jack on the front panel.
CAT: The USB jack on the rear panel.
DAKY: The RTTY/DATA jack on the rear
panel.
RTS: The USB jack on the rear panel.
DTR: The USB jack on the rear panel.
VOX: Terminal set with “VOX SELECT”.
USB MOD GAIN
Function: Sets the level of the DATA signal input
when “MOD SOURCE” is set to “USB”.
Available Values: 0 - 100
Default Setting: 50
REAR MOD GAIN
Function: Sets the level of the DATA signal in-
put when “MOD SOURCE” is set to
“REAR”.
Available Values: 0 - 100
Default Setting: 50
RPTT SELECT
Function: Sets the PTT control for the DATA
transmit signal.
Available Values: OFF / RTS / DTR / DAKY
Default Setting: OFF
Description:
OFF: No PTT control.
RTS: Controls the DATA transmit signal from
the USB virtual COM/RTS ports.
DTR: Controls the DATA transmit signal from
the USB virtual COM/DTR ports.
DAKY: Controls the DATA transmit signal from
the RTTY/DATA jack (pin 3) on the rear
panel.
83
