Parameter Details
12
12.2 A: Initialization Parameters
YASKAWA SIEPC71061753C GA500 Technical Manual 493
No. Name Optimal Value
L8-07 Output Phase Loss Protection Sel 1: Fault when One Phase is Lost
L8-41 High Current Alarm Selection 1: Enabled
The drive saves the parameters in Table 12.17 as User Parameters.
Table 12.17 Parameters Saved as User Parameters with the Traveling Preset
User Parameter No. Parameter No. Saved Name
A2-01 b1-01 Frequency Reference Selection 1
A2-02 C1-01 Acceleration Time 1
A2-03 C1-02 Deceleration Time 1
A2-04 C6-02 Carrier Frequency Selection
A2-05 d1-01 Reference 1
A2-06 d1-02 Reference 2
A2-07 d1-03 Reference 3
A2-08 E2-01 Motor Rated Current (FLA)
A2-09 H1-05 Terminal S5 Function Selection
A2-10 H1-06 Terminal S6 Function Selection
A2-11 H2-01 Term MA/MB-MC Function Selection
A2-12 L1-01 Motor Overload (oL1) Protection
8 : Conveyor 2
The drive automatically sets the parameters in Table 12.18 for a conveyor 2 application.
Table 12.18 Best Parameter Settings for Conveyor 2 Application
No. Name Optimal Value
A1-02 Control Method Selection 0: V/f Control
C1-01 Acceleration Time 1 3.0 s
C1-02 Deceleration Time 1 3.0 s
C6-01 Normal / Heavy Duty Selection 0: Heavy Duty Rating
L3-04 Stall Prevention during Decel 7: Overexcitation/High Flux 3
n3-13 OverexcitationBraking (OEB) Gain 1.40
n3-21 HSB Current Suppression Level 150
The drive saves the parameters in Table 12.19 as User Parameters.
Table 12.19 Parameters Saved as User Parameters with the Conveyor 2 Preset
User Parameter No. Parameter No. Saved Name
A2-01 A1-02 Control Method Selection
A2-02 b1-01 Frequency Reference Selection 1
A2-03 b1-02 Run Command Selection 1
A2-04 C1-01 Acceleration Time 1
A2-05 C1-02 Deceleration Time 1
A2-06 E2-01 Motor Rated Current (FLA)
A2-07 L3-04 Stall Prevention during Decel
A2-08 n3-13 OverexcitationBraking (OEB) Gain
A2-09 n3-21 HSB Current Suppression Level
■ Notes for Elevator or Lift Applications
When you use the drive for elevator or lift applications, read the safety descriptions and precautions, and safely
and correctly use the device.
