3.2 Operating Procedures for Utility Functions
3.2.28 Advanced Autotuning without Reference (Fn201)
3-74
6
Press the Key if the stroke is
set to a positive value, or press the
Key if the stroke is set to a
negative value.
Calculation of the moment of inertia
will start.
While the moment of inertia is being
calculated, the setting of Pn103 will
flash and 1:ADJ will flash instead of
1:RUN.
When calculating the moment of
inertia has been completed, the dis-
play will stop flashing and the
moment of inertia will be displayed.
The servo will remain ON, but auto-
matic operation will stop temporar-
ily.
Note: 1. Calculating the moment of iner-
tia will not start if the sign of the
stroke does not agree with the
key that is pressed ( Key
or Key).
2. If Jcalc is set to OFF, calculat-
ing the moment of inertia will
not start and the setting of
Pn103 will be displayed.
3. If NO-OP or ERROR is dis-
played during operation, press
the Key to cancel the
operation and refer to the fol-
lowing section to correct the
problem.
3.2.28 Advanced Auto-
tuning without Reference
(Fn201) -Troubleshooting
Problems in the Opera-
tion on page 3-76
Continued on next page.
Continued from previous page.
Step Operation Result
1:RUN AAT
Pn103 =003 00
Pn100=0040.0
Pn101=0020.0
Pn141=0050.0
Display Example: After Calcu-
lating the Moment of Inertia
To Next Page
