5.1 A: Initialization Parameters
178 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
Note:
• Before you set A1-06, make sure that you set A1-03 = 2220 [Initialize Parameters = 2-Wire Initialization] to initialize parameters.
• It is not possible to change the A1-06 value. To set an application preset, first set A1-03 = 2220 to initialize parameters, then set this
parameter. If initializing all parameters will cause a problem, do not change the settings.
If you set A2-33 = 1 [User Parameter Auto Selection = Enabled: Auto Save Recent Parms] to set parameters to A2-17 to A2-32 [User
Parameters 17 to 32] automatically, the drive will reset these parameters when you change the A1-06 setting.
0 : No Preset Selected
The drive saves the parameters in Table 5.3 as user parameters.
Table 5.3 Parameters Saved as User Parameters with the No Preset Selected
User Parameter No. Parameter No. Saved Name
A2-01
b1-01 Frequency Reference Selection 1
A2-02
b1-02 Run Command Selection 1
A2-03
b1-03 Stopping Method Selection
A2-04
C1-01 Acceleration Time 1
A2-05
C1-02 Deceleration Time 1
A2-06
C6-02 Carrier Frequency Selection
A2-07
d1-01 Reference 1
A2-08
d1-02 Reference 2
A2-09
d1-03 Reference 3
A2-10
d1-04 Reference 4
A2-11
d1-17 Jog Reference
A2-12
E1-01 Input AC Supply Voltage
A2-13
E1-03 V/f Pattern Selection
A2-14
E1-04 Maximum Output Frequency
A2-15
E1-05 Maximum Output Voltage
A2-16
E1-06 Base Frequency
A2-17 E1-09 Minimum Output Frequency
A2-18 E1-13 Base Voltage
A2-19 E2-01 Motor Rated Current (FLA)
A2-20 E2-04 Motor Pole Count
A2-21 E2-11 Motor Rated Power
A2-22 H4-02 Terminal FM Analog Output Gain
A2-23 L1-01 Motor Overload (oL1) Protection
A2-24 L3-04 Stall Prevention during Decel
A2-25
- -
1 : General Purpose Fan
The drive automatically sets the parameters in Table 5.4 for a general purpose fan application.
Table 5.4 Best Parameter Settings for General Purpose Fan Applications
No. Name Optimal Value
A1-02
Control Method Selection
0: V/f Control
b1-03
Stopping Method Selection
1: Coast to Stop
b1-04
Reverse Operation Selection
1: Reverse Disabled
C1-01
Acceleration Time 1 60.0 s
L5-01
Number of Auto-Restart Attempts
10
The drive saves the parameters in Table 5.5 as user parameters.
