Receiving
1
1.2 Catalog Code and Nameplate Check
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 27
Figure 1.5 Enclosed Bypass Catalog Code
Table 1.4 Enclosed Bypass Catalog Code Details
No. Description
1 Product series
2 Bypass type
• 1: Enclosed
3 Input power supply voltage
• D: Three-Phase 208 V
• A: Three-Phase 240 V
• B: Three-Phase 480 V
4 Bypass output amps
5 Power options
• B: 3-contactor bypass
• F: Input fuses
• G: Drive input service switch
• M: Lockable circuit breaker (100 kA SCCR Panel Rating)
6 Control options
• D: EtherNet/IP
• L: LonWorks
• W: Custom nameplate
• K: Control transformer - 200 VA additional
• Z: Speed potentiometer
â– Enclosed Bypass Models, Drive Models, and Capacities
Table 1.5 Three-Phase AC 208 V Enclosed Models and Capacities (NEMA Rating)
Bypass Model
H6B1
Capacity
Drive Catalog Code
HV60U
Electrical Schematic Weight (lb)
HP Input (A) Output (A)
D002 0.5 3.8 2.4 2011
DS.H6B1.01 93
D003 0.75 4.9 3.5 2011
DS.H6B1.01 93
D004 1 6.0 4.6 2011
DS.H6B1.01 93
D007 2 8.9 7.5 2011
DS.H6B1.01 93
D010 3 12.0 10.6 2011
DS.H6B1.01 93
D016 5 18.1 16.7 2017
DS.H6B1.01 93
D024 7.5 25.6 24.2 2024
DS.H6B1.01 125
D030 10 32.2 30.8 2031
DS.H6B1.01 128
D046 15 48.6 46.2 2046
DS.H6B1.01 159
D059 20 61.8 59.4 2059
DS.H6B1.01 163
D074 25 77.2 74.8 2075
DS.H6B1.01 224
D088 30 90.4 88 2088
DS.H6B1.01 233
D114 40 116.4 114 2114
DS.H6B1.01 248
D143 50 145.4 143 2143
DS.H6B1.01 419
D169 60 171.4 169 2169
DS.H6B1.01 434
D211 75 212.4 211 2211
DS.H6B1.01 832
D273 100 275.4 273 2273
DS.H6B1.01 859
1 2 4
H6B 1 D 004 P T S
3
W/L/D
5 6
M/F/G
B/W/R
H/K/A/Y
