1.2 Catalog Code and Nameplate Check
28 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
Table 1.6 Three-Phase AC 240 V Enclosed Models and Capacities (NEMA Rating)
Bypass Model
H6B1
Capacity
Drive Catalog Code
HV60U
Electrical Schematic Weight (lb)
HP Input (A) Output (A)
A002 0.5 3.5 2.2 2011
DS.H6B1.01 93
A003 0.75 4.5 3.2 2011
DS.H6B1.01 93
A004 1 5.5 4.2 2011
DS.H6B1.01 93
A006 2 8.1 6.8 2011
DS.H6B1.01 93
A009 3 10.9 9.6 2011
DS.H6B1.01 93
A015 5 16.5 15.2 2017
DS.H6B1.01 93
A022 7.5 23.3 22 2024
DS.H6B1.01 125
A028 10 29.3 28 2031
DS.H6B1.01 128
A042 15 44.1 42 2046
DS.H6B1.01 159
A054 20 56.1 54 2059
DS.H6B1.01 163
A068 25 70.1 68 2075
DS.H6B1.01 224
A080 30 82.1 80 2088
DS.H6B1.01 228
A104 40 106.1 104 2114
DS.H6B1.01 243
A130 50 132.1 130 2143
DS.H6B1.01 414
A154 60 156.1 154 2169
DS.H6B1.01 430
A192 75 193.3 192 2211
DS.H6B1.01 803
A248 100 250.1 248 2273
DS.H6B1.01 859
Table 1.7 Three-Phase AC 480 V Enclosed Models and Capacities (NEMA Rating)
Bypass Model
H6B1
Capacity
Drive Catalog Code
HV60U
Electrical Schematic Weight (lb)
HP Input (A) Output (A)
B001 0.75 2.2 1.6 4005
DS.H6B1.01 93
B002 1 2.7 2.1 4005
DS.H6B1.01 93
B003 2 4.0 3.4 4005
DS.H6B1.01 93
B004 3 5.4 4.8 4005
DS.H6B1.01 93
B007 5 8.2 7.6 4008
DS.H6B1.01 94
B011 7.5 11.6 11 4011
DS.H6B1.01 94
B014 10 14.6 14 4014
DS.H6B1.01 94
B021 15 21.6 21 4021
DS.H6B1.01 125
B027 20 27.6 27 4027
DS.H6B1.01 129
B034 25 35.0 34 4034
DS.H6B1.01 137
B040 30 41.0 40 4040
DS.H6B1.01 162
B052 40 53.0 52 4052
DS.H6B1.01 168
B065 50 66.0 65 4065
DS.H6B1.01 179
B077 60 78.0 77 4077
DS.H6B1.01 233
B096 75 97.0 96 4096
DS.H6B1.01 247
B124 100 125.0 124 4124
DS.H6B1.01 263
B156 125 157.0 156 4156
DS.H6B1.01 431
B180 150 180.6 180 4180
DS.H6B1.01 803
B240 200 241.0 240 4240
DS.H6B1.01 857
B302 250 303.0 302 4302
DS.H6B1.01 964
