YASKAWA HV600 User Manual

5.7 H: Terminal Functions
290 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
■ 53: Sequence Timer 3
Setting Value Function Description
53 Sequence Timer 3 The terminal activates when Sequence Timer 3 is active.
■ 54: Sequence Timer 4
Setting Value Function Description
54 Sequence Timer 4 The terminal activates when Sequence Timer 4 is active.
■ 58: UL6 Underload Detected
Setting Value Function Description
58 UL6 Underload Detected The terminal activates when the drive detected UL6 [Underload or Belt Break Detected].
■ 60: Internal Cooling Fan Failure
Setting Value Function Description
60 Internal Cooling Fan Failure The terminal activates when the drive detects a cooling fan failure in the drive.
■ 62: Modbus Reg 1 Status Satisfied
Setting Value Function Description
62 Modbus Reg 1 Status
Satisfied
The terminal activates when the bit specified by H2-08 [Modbus Register 1 Bit Select] for the MEMOBUS register address set with
H2-07 [Modbus Register 1 Address Select] activates.
■ 63: Modbus Reg 2 Status Satisfied
Setting Value Function Description
63 Modbus Reg 2 Status
Satisfied
The terminal activates when the bit specified by H2-10 [Modbus Register 2 Bit Select] for the MEMOBUS register address set with
H2-09 [Modbus Register 2 Address Select] activates.
■ 69: External Power 24V Supply
Setting Value Function Description
69 External Power 24V Supply The terminal activates when there is an external 24V power supply between terminals PS-AC.
ON : An external 24V power supply supplies power.
OFF : An external 24V power supply does not supply power.
■ 6A: Data Logger Error
Setting Value Function Description
6A Data Logger Error The terminal activates when the drive detects LoG [Com Error / Abnormal SD card].
■ 71: Low PI2 Control Feedback Level
Setting Value Function Description
71 Low PI2 Control Feedback
Level
The terminal activates when the PI2 Control Feedback Level is less than S3-13 [PI2 Control Low Feedback Lvl].
■ 72: High PI2 Control Feedback Level
Setting Value Function Description
72 High PI2 Control Feedback
Level
The terminal activates when the PI2 Control Feedback Level is more than S3-15 [PI2 Control High Feedback Lvl].
