YASKAWA HV600 User Manual

Parameter Details
5
5.7 H: Terminal Functions
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 315
■ H7-16: Virtual Multi-Function Output 4
No.
(Hex.)
Name Description
Default
(Range)
H7-16
(11AA)
Expert
Virtual Multi-Function
Output 4
Sets the function for virtual digital output 4. F
(0 - 1A7)
■ H7-17: Virtual Output 4 Delay Time
No.
(Hex.)
Name Description
Default
(Range)
H7-17
(11AB)
Expert
Virtual Output 4 Delay Time Sets the minimum ON time for virtual digital output 4. 0.1 s
(0.0 - 25.0 s)
■ H7-30: Virtual Analog Input Selection
No.
(Hex.)
Name Description
Default
(Range)
H7-30
(1177)
Expert
Virtual Analog Input
Selection
Sets the virtual analog input function. F
(0 - 31)
■ H7-31: Virtual Analog Input Gain
No.
(Hex.)
Name Description
Default
(Range)
H7-31
(1178)
RUN
Expert
Virtual Analog Input Gain Sets the virtual analog input gain. 100.0%
(-999.9 - 999.9%)
■ H7-32: Virtual Analog Input Bias
No.
(Hex.)
Name Description
Default
(Range)
H7-32
(1179)
RUN
Expert
Virtual Analog Input Bias Sets the virtual analog input bias. 0.0%
(-999.9 - 999.9%)
■ H7-40: Virtual Analog Out Signal Select
No.
(Hex.)
Name Description
Default
(Range)
H7-40
(1163)
Virtual Analog Out Signal
Select
Sets the signal level of the virtual analog output. 0
(0 - 2)
0 : 0 to 100% (Absolute Value)
1 : -100 to 100%
2 : 0 to 100% (Lower Limit at 0)
■ H7-41: Virtual Analog Output Function
No.
(Hex.)
Name Description
Default
(Range)
H7-41
(1164)
Virtual Analog Output
Function
Sets the monitor to be output from the virtual analog output. 102
(0 - 999)
Set the x-xx part of the Ux-xx [Monitor]. For example, set H7-41 = 102 to monitor U1-02 [Output Frequency].
