5.7 H: Terminal Functions
314 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
■ H7-04: Virtual Multi-Function Input 4
No.
(Hex.)
Name Description
Default
(Range)
H7-04
(1188)
Expert
Virtual Multi-Function Input
4
Sets the function that enters the virtual input set in H7-16 [Virtual Multi-Function Output 4]. F
(1 - 1B8)
Note:
Settings 1B [Programming Lockout] and 11B [!Programming Lockout] are not available.
■ H7-10: Virtual Multi-Function Output 1
No.
(Hex.)
Name Description
Default
(Range)
H7-10
(11A4)
Expert
Virtual Multi-Function
Output 1
Sets the function for virtual digital output 1. F
(0 - 1A7)
■ H7-11: Virtual Output 1 Delay Time
No.
(Hex.)
Name Description
Default
(Range)
H7-11
(11A5)
Expert
Virtual Output 1 Delay Time Sets the minimum ON time for virtual digital output 1. 0.1 s
(0.0 - 25.0 s)
■ H7-12: Virtual Multi-Function Output 2
No.
(Hex.)
Name Description
Default
(Range)
H7-12
(11A6)
Expert
Virtual Multi-Function
Output 2
Sets the function for virtual digital output 2. F
(0 - 1A7)
■ H7-13: Virtual Output 2 Delay Time
No.
(Hex.)
Name Description
Default
(Range)
H7-13
(11A7)
Expert
Virtual Output 2 Delay Time Sets the minimum ON time for virtual digital output 2. 0.1 s
(0.0 - 25.0 s)
■ H7-14: Virtual Multi-Function Output 3
No.
(Hex.)
Name Description
Default
(Range)
H7-14
(11A8)
Expert
Virtual Multi-Function
Output 3
Sets the function for virtual digital output 3. F
(0 - 1A7)
■ H7-15: Virtual Output 3 Delay Time
No.
(Hex.)
Name Description
Default
(Range)
H7-15
(11A9)
Expert
Virtual Output 3 Delay Time Sets the minimum ON time for virtual digital output 3. 0.1 s
(0.0 - 25.0 s)

YASKAWA HV600 Specifications

General

Category	DC Drives
Series	HV600
Overload Capacity	150% for 60 seconds
Output Voltage	0 - Input Voltage
Enclosure	NEMA 1, NEMA 12
Communication	Ethernet/IP, Modbus, DeviceNet, Profibus
Safety	Safe Torque Off (STO)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short Circuit
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m (3280ft) without derating
Control Method	Vector Control
