5.10 o: Keypad-Related Settings
360 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
0 : Custom Monitor
1 : Bar Graph
2 : Analog Gauge
3 : Trend Plot
■ o1-41: 1st Monitor Area Selection
No.
(Hex.)
Name Description
Default
(Range)
o1-41
(11C1)
RUN
1st Monitor Area Selection Sets the horizontal range used to display the monitor set in o1-24 [Custom Monitor 1] as a bar graph.
This parameter is only available on an HOA keypad.
0
(0 - 1)
0 : +/- Area ( - o1-42 ~ o1-42 )
1 : + Area ( 0 ~ o1-42 )
■ o1-42: 1st Monitor Area Setting
No.
(Hex.)
Name Description
Default
(Range)
o1-42
(11C2)
RUN
1st Monitor Area Setting Sets the horizontal axis value used to display the monitor set in o1-24 [Custom Monitor 1] as a bar
graph. This parameter is only available on an HOA keypad.
100.0%
(0.0 - 100.0%)
■ o1-43: 2nd Monitor Area Selection
No.
(Hex.)
Name Description
Default
(Range)
o1-43
(11C3)
RUN
2nd Monitor Area Selection Selects the horizontal range used to display the monitor set in o1-25 [Custom Monitor 2] as a bar
graph. This parameter is only available on an HOA keypad.
0
(0 - 1)
0 : +/- Area ( - o1-44 ~ o1-44 )
1 : + Area ( 0 ~ o1-44 )
■ o1-44: 2nd Monitor Area Setting
No.
(Hex.)
Name Description
Default
(Range)
o1-44
(11C4)
RUN
2nd Monitor Area Setting Sets the horizontal axis value used to display the monitor set in o1-25 [Custom Monitor 2] as a bar
graph. This parameter is only available on an HOA keypad.
100.0%
(0.0 - 100.0%)
■ o1-45: 3rd Monitor Area Selection
No.
(Hex.)
Name Description
Default
(Range)
o1-45
(11C5)
RUN
3rd Monitor Area Selection Sets the horizontal range used to display the monitor set in o1-26 [Custom Monitor 3] as a bar graph.
This parameter is only available on an HOA keypad.
0
(0 - 1)
0 : +/- Area ( - o1-46 ~ o1-46 )
1 : + Area ( 0 ~ o1-46 )
■ o1-46: 3rd Monitor Area Setting
No.
(Hex.)
Name Description
Default
(Range)
o1-46
(11C6)
RUN
3rd Monitor Area Setting Sets the horizontal axis value used to display the monitor set in o1-26 [Custom Monitor 3] as a bar
graph. This parameter is only available on an HOA keypad.
100.0%
(0.0 - 100.0%)
