5.10 o: Keypad-Related Settings
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 361
■ o1-47: Trend Plot 1 Scale Minimum Value
No.
(Hex.)
Name Description
Default
(Range)
o1-47
(11C7)
RUN
Trend Plot 1 Scale Minimum
Value
Sets the horizontal axis minimum value used to display the monitor set in o1-24 [Custom Monitor 1]
as a trend plot. This parameter is only available on an HOA keypad.
-100.0%
(-300.0 - +300.0%)
■ o1-48: Trend Plot 1 Scale Maximum Value
No.
(Hex.)
Name Description
Default
(Range)
o1-48
(11C8)
RUN
Trend Plot 1 Scale
Maximum Value
Sets the horizontal axis maximum value used to display the monitor set in o1-24 [Custom Monitor 1]
as a trend plot. This parameter is only available on an HOA keypad.
100.0%
(-300.0 - +300.0%)
■ o1-49: Trend Plot 2 Scale Minimum Value
No.
(Hex.)
Name Description
Default
(Range)
o1-49
(11C9)
RUN
Trend Plot 2 Scale Minimum
Value
Sets the horizontal axis minimum value used to display the monitor set in o1-25 [Custom Monitor 2]
as a trend plot. This parameter is only available on an HOA keypad.
-100.0%
(-300.0 - +300.0%)
■ o1-50: Trend Plot 2 Scale Maximum Value
No.
(Hex.)
Name Description
Default
(Range)
o1-50
(11CA)
RUN
Trend Plot 2 Scale
Maximum Value
Sets the horizontal axis maximum value used to display the monitor set in o1-25 [Custom Monitor 2]
as a trend plot. This parameter is only available on an HOA keypad.
100.0%
(-300.0 - +300.0%)
■ o1-51: Trend Plot Time Scale Setting
No.
(Hex.)
Name Description
Default
(Range)
o1-51
(11CB)
RUN
Trend Plot Time Scale
Setting
Sets the time scale (horizontal axis) to display the trend plot. When you change this setting, the drive
automatically adjusts the data sampling time. This parameter is only available on an HOA keypad.
300 s
(1 - 3600 s)
■ o1-55: Analog Gauge Area Selection
No.
(Hex.)
Name Description
Default
(Range)
o1-55
(11EE)
RUN
Analog Gauge Area
Selection
Sets the range used to display the monitor set in o1-24 [Custom Monitor 1] as an analog gauge. This
parameter is only available on an HOA keypad.
1
(0, 1)
0 : +/- Area ( - o1-56 ~ o1-56 )
1 : + Area ( 0 ~ o1-56 )
■ o1-56: Analog Gauge Area Setting
No.
(Hex.)
Name Description
Default
(Range)
o1-56
(11EF)
RUN
Analog Gauge Area Setting Sets the value used to display the monitor set in o1-24 [Custom Monitor 1] as an analog meter. This
parameter is only available on an HOA keypad.
100.0%
(0.0 - 100.0%)
